Advantech 6 DO/6 DI Power Relay Module (ADAM-6066-D)
Deskripsi
| Category | Attribute | Value |
| General | Connectors | 1 x RJ45, 1 x 13-pin plug-in screw terminal, 1 x 9-pin plug-in screw terminal |
| Protocol | Modbus/TCP, TCP/IP, UDP, HTTP, DHCP, MQTT, SNMP, ASCII command | |
| Communications | Interface | Ethernet |
| Isolated Digital Input | Channels | 6 |
| Input Voltage | Dry Contact Logic level 0: close to GND Logic level 1: open Wet Contact Logic level 1: 10~30 VDC Logic level 0: 0~3 VDC | |
| Environment | Isolation Voltage | 2,000 VDC |
| Operating Temperature | (-40~70 °C) (-40~158 °F) | |
| Isolated Digital Output | Channels | 6 |
| Output Type | Source | |
| Contact Rating (Resistive) | 3 A @ 30 VDC, 5 A @ 250 VAC | |
| Relay Type | 1 x Form A | |
| Power Requirements | Input Voltage | 10~30 VDC |
