Schneider SCREW TERMINAL, FEED THROUGH, 2 POINTS, 35MM²
Rp92.300
Deskripsi
| Range | Linergy |
|---|---|
| Product name | Linergy TR |
| Product or component type | Terminal block |
| Device short name | TRV |
| Terminal block type | Passthrough |
| Terminal block level | 1 |
| Mounting mode | Clip-on |
| nominal cross section | 35 mm² |
| Length | 60.2 mm |
| colour | Grey |
| Quantity per set | Set of 50 |
| Width | 16 mm |
|---|---|
| Height | 65.7 mm |
| connections – terminals | 1 x screw terminal: upstream 1 x screw terminal: downstream |
| number of connections | 2 |
| Connection position | Sideways |
| Number of measurement input | 2 |
| cable cross section | 1.5…50 mm², flexible cable without cable end 1.5…50 mm², solid cable |
| tightening torque | 3.2…3.7 N.m |
| Wire stripping length | 18 mm |
| tool type | Connection: screwdriver Disconnection: screwdriver |
| [Ue] rated operational voltage | 1000 V conforming to EN/IEC 60947-7-1 600 V CSA 690 V conforming to ATEX Exe II Ex II 2 GD 600 V cURus |
| [In] rated current | 125 A conforming to EN/IEC 60947-7-1 150 A cURus 150 A CSA 126 A conforming to ATEX Exe II Ex II 2 GD |
| material | Polyamide 6/6: insulating case |
| dielectric loss | 0.01 at 1 MHz conforming to IEC 60250 0.01 at 1 MHz conforming to VDE 0303-T4 |
| dielectric constant | 3.7 at 1 MHz |
| resistivity | 10000 MΩ.m conforming to IEC 60093 10000 MΩ.m conforming to VDE 0303-T30 |
| surface resistance | 1000 GΩ conforming to IEC 60093 1000 GΩ conforming to VDE 0303-T30 |
| creep resistance | 500 CTI (> 400 kB) conforming to IEC 60093 500 CTI (> 400 kB) conforming to VDE 0303-T30 |
| flame retardance | V0, thickness0.8 mm conforming to UL 94 |
| Net weight | 61 g |
| range compatibility | Prisma G Prisma P Prisma PH Prisma Pack Spacial Kaedra Pragma TeSys |
| Product compatibility | Spacial enclosures |
| Product certifications | ATEX IEC-Ex VDE EAC GL CSA cURus |
|---|---|
| dielectric strength | 1000 V conforming to IEC 60243-1 |
| ambient air temperature for operation | -40…130 °C conforming to IEC 60216-1 -40…130 °C conforming to VDE 0304-T21 |
