Schneider mini Pragma surface enclosure – 1 x 4 modules – plain door
Rp277.489
Deskripsi
Spesifikasi MIP12104
| Range | Resi9 |
|---|---|
| Product name | Resi9 MP |
| Product or component type | Enclosure |
| Enclosure type | Modular enclosure |
| Nb of 18 mm modules per row | 4 |
| Nb of horizontal rows | 1 |
| Type of door | Plain |
| Width | 124 mm outside: |
| Height | 198 mm outside: |
| Depth | 95 mm outside: |
| Enclosure mounting | Surface |
|---|---|
| 9 mm pitches | 8 |
| Total number of 18 mm modules | 4 |
| [In] rated current | 50 A |
| type of rail | 35 mm asymmetrical rail |
| Mounting plate description | Without mounting plate |
| Cable entry | 1 bare flange 1 trunking flange |
| Terminal block function | Earth / neutral |
| Number of terminal blocks | 1 earth (screwed) with 4 outgoers 1 neutral (screwed) with 4 outgoers |
| Distribution block outgoers | 1 x 16 mm² for earth 1 x 16 mm² for neutral 1 x 6 mm² for earth 1 x 6 mm² for neutral 2 x 10 mm² for earth 2 x 10 mm² for neutral |
| Enclosure material | Back part: technoplastic Door: technoplastic Front face: technoplastic |
| Internal depth | 74 mm |
| Colour | Door: white (RAL 9003) Front face: white (RAL 9003) |
| Market segment | Small commercial Residential |
| standards | IEC 61439-1 IEC 61439-3 IEC 60670-1 IEC 60670-24 |
|---|---|
| Quality labels | IMQ |
| Fire resistance | Door: 650 °C Back part: 650 °C Front face: 650 °C |
| IP degree of protection | IP40 |
| IK degree of protection | IK07 |
| Ambient air temperature for operation | -25…60 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 9.55 cm |
| Package 1 Width | 12.4 cm |
| Package 1 Length | 19.8 cm |
| Package 1 Weight | 400 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 20 |
| Package 2 Height | 52 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 8.1 kg |
| Unit Type of Package 3 | P12 |
| Number of Units in Package 3 | 160 |
| Package 3 Height | 60 cm |
| Package 3 Width | 80 cm |
| Package 3 Length | 120 cm |
| Package 3 Weight | 76.8 kg |
| Warranty | 12 months |
|---|
