WD Purple Pro Smart Video Hard Drive - 10TB
Rp6.696.000
POLYTRON 24 inch LED SMART TV PLD24CV1869
Rp2.149.238
Ruijie RG-RSR30-XA-24 24-Port Multi-service Fixed Aggregation Router
Rp90.123.120
Deskripsi
Specifications
| Hardware Specifications | RG-RSR30-XA-24 |
| Port Specifications | |
| Fixed service port | 16 x 10/100/1000BASE-T ports
8 x 10GE SFP+ ports |
| Fixed management port | 1 x RJ45 console port |
| USB | 1 x USB 2.0 port (Type-A connector) |
| Module slot | 4 x expansion module slots
2 x power module slots |
| System Specifications | |
| Switching capacity | 272 Gbps |
| Packet forwarding rate | 4 Mpps |
| ARP table size | 24,000 |
| Number of IPv4 unicast routes | 300,000 |
| Number of IPv4 multicast routes | 2,048 |
| Number of IPv6 unicast routes | 300,000 |
| Number of IPv6 multicast routes | 1,024 |
| Number of IGMP groups | 1,000 |
| Number of MLD groups | 1,000 |
| Number of ACEs | 16,000 |
| Dimensions and Weight | |
| Unit dimensions (W x D x H) | 440 mm x 420 mm x 44 mm (17.32 inch. x 16.56 in. x 1.73 in.) |
| Rack height | 1 RU |
| Unit weight | < 7.8 kg (17.19 lbs, full configuration without packaging materials, with the nameplate at the bottom) |
| Power supply and consumption | |
| Maximum power consumption | 150 W |
| Power module redundancy | 1+1 redundancy |
| Power input | RG-PA150IB-F (AC input)：
● Rated input voltage: 100 V AC to 240 V AC, 50 Hz to 60 Hz ● Maximum input voltage: 90 V AC to 264 V AC, 47 Hz to 63 Hz ● Maximum input current: 3 A RG-PD150IB-F (DC input)： ● Rated input voltage: -48V~-60V DC ● Maximum input voltage: -36V~-75V DC ● Maximum input current: 5 A |
| Power output | RG-PA150IB-F (AC input):
● Output voltage: 12 V ● Maximum output corrent: 12.5 A RG-PD150IB-F (DC input): ● Output voltage: 12 V ● Maximum output corrent: 12.5 A |
| Maximum output power | RG-PA150IB-F: 150 W
RG-PD150IB-F: 150 W |
| Environment and Reliability | |
| Temperature | Operating temperature: 0°C to 50°C (32°F to 122°F)
Storage temperature: –40°C to 70°C (–40°F to +158°F) |
| Humidity | Operating humidity: 10% to 90% RH (non-condensing)
Storage humidity: 5% to 95% RH (non-condensing) |
| Altitude | Operating altitude: 0 m to 5,000 m (0 ft. to 16,404.20 ft.)
Storage altitude: 0 m to 5,000 m (0 ft. to 16,404.20 ft.) |
| Surge protection | 6 kV |
| Software Specifications RG-RSR30-XA Series | |
| Model | Description |
| Ethernet switching | Jumbo frame length: 2,000 bytes |
| 802.3az EEE | |
| LLDP/LLDP-MED | |
| IP service | Static and dynamic ARP |
| DHCP server, DHCP relay, and DHCP client | |
| FTP, TFTP, FTPv6, and TFTPv6 | |
| NTP, SNTP, and NTPv6 | |
| NAT | |
| Strict and loose RPF
uRPF ignoring default routes |
|
| ND | |
| DNS | |
| IPv4/IPv6 VRF | |
| DHCP server, DHCPv6 client, and DHCPv6 relay | |
| ND and ND snooping | |
| IPv6 GRE tunnel | |
| IP routing | IPv4 and IPv6 static routing, and static blackhole routes |
| RIP v1/v2 and RIPng | |
| OSPFv2 and OSPFv3 | |
| IS-ISv4 and IS-ISv6 | |
| BGP and BGP4+ | |
| Routing policies | |
| BGP4, BGP4+, and MP-BGP | |
| IPv4 VRRP v2/v3 and IPv6 VRRP v3 | |
| IPv4 and IPv6 PBR | |
| Multicast | IGMP v1/v2/v3 |
| Static multicast routing | |
| PIM-DM, PIM-SM, PIM-SSM, PIM-SSMv6, PIM-SMv6, and other multicast routing protocols | |
| MSDP for inter-domain multicast | |
| MLDv1/v2 | |
| MPLS | Basic MPLS functions |
| MPLS forwarding | |
| 6PE/6VPE interconnection with IPv4/IPv6 MPLS backbone network | |
| MPLS MIB (RFC 1273, 4265, 4382) | |
| L3VPN | |
| LSP | |
| LDP | |
| ACL and QoS | Standard IP ACLs |
| Extended IP ACLs | |
| Extended MAC ACLs | |
| IPv6 ACLs | |
| Applying ACLs to interfaces | |
| MPLS QoS | |
| Security | Multiple AAA modes |
| RADIUS authentication, authorization, and accounting | |
| TACACS+ | |
| Attack defense | |
| Password security | |
| RNFP | |
| CPP | |
| FPM | |
| PKI | |
| IPsec VPN(AES-128,AES-256) | |
| VPDN | |
| SSHv1 and SSHv2 | |
| Global IP-MAC binding | |
| Login authentication and password security | |
| Reliability | BFD |
| GR | |
| DLDP | |
| ECMP | |
| Hot swapping | |
| NMS and maintenance | SPAN and ERSPAN |
| SNMP v1/v2c/v3 | |
| System operation logging | |
| IPFIX | |
| Command line configuration through console, AUX Modem, Telnet, and SSH | |
| RMON (1, 2, 3, 9) | |
| NETCONF | |
| CWMP | |
| gRPC | |
| Interface | Ethernet interface |
