Ruijie RG-AP710 Wireless Access Point
Rp1.676.766
- The Ruijie AP710 is a cost effective 802.11ac access point with 2×2 MIMO and concurrent Dual-band design, data rate of upto 1.167Gbps.
| Model | Ruijie AP730-L | Ruijie AP720-L | Ruijie AP710 | Ruijie AP210-L | |
|---|---|---|---|---|---|
| Model | Ruijie AP730-L | Ruijie AP720-L | Ruijie AP710 | Ruijie AP210-L | |
| Target Deployment | SME High Density Wi-Fi | Retail Chain Store, Small & Medium-sized Business Office, Boutique Hotel | |||
| Type | Indoor Ceiling/Wall-mounting | ||||
| Basic Spec | Radio | Tri-band (2.4G+5G+5G) | Concurrent Dual-band | Single-band | |
| Protocol | 802.11a/b/g/n/ac
Wave2 |
802.11a/b/g/n/ac
|
802.11b/g/n | ||
| Operating Bands | 802.11b/g/n: 2.4GHz to 2.483GHz
802.11a/n/ac: 5.150GHz to 5.350GHz, 5.47GHz to 5.725GHz, 5.725GHz to 5.850GHz (vary depending on countries) |
802.11b/g/n: 2.4GHz to 2.483GHz
|
|||
| Antenna | Built-in Omni-directional Antenna | ||||
| Antenna Gain | 2.4G: 3dBi
5G: 3dBi |
2.4G: 3dBi | |||
| Max Throughput | Maximum throughput of 2.4G: 400Mbps
Maximum throughput of 5G: 1.73Gbps Maximum throughput per AP: 2.13Gbps |
Maximum throughput of 2.4G: 300Mbps
Maximum throughput of 5G: 867Mbps Maximum throughput per AP: 1167Mbps |
Maximum throughput of 2.4G: 300Mbps
Maximum throughput of 5G: 8.67Gbps Maximum throughput per AP: 1167Mbps |
Maximum throughput of 2.4G: 300Mbps
Maximum throughput per AP: 300Mbps |
|
| Modulation | OFDM：BPSK@6/9Mbps，QPSK@12/18Mbps，16-QAM@24Mbps，64-QAM@48/54Mbps
DSSS：DBPSK@1Mbps，DQPSK@2Mbps，and [email protected]/11Mbps MIMO-OFDM：BPSK, QPSK, 16QAM, 64QAM, 256QAM |
OFDM：BPSK@6/9Mbps，QPSK@12/18Mbps，16-QAM@24Mbps，64-QAM@48/54Mbps
DSSS：DBPSK@1Mbps，DQPSK@2Mbps，and [email protected]/11Mbps MIMO-OFDM：BPSK, QPSK, 16QAM, 64QAM |
|||
| Receiver Sensitivity | 11b：-96dBm（1Mbps），-93dBm（5Mbps），-89dBm（11Mbps）
11a/g：-91dBm（6Mbps），-85dBm（24Mbps），-80dBm（36Mbps），-74dBm（54Mbps） 11n：-90dBm（MCS0），-70dBm（MCS7），-89dBm（MCS8），-68dBm（MCS15） 11ac HT20：-88dBm（MCS0）, -63dBm（MCS9） 11ac HT40：-85dBm（MCS0）, -60dBm（MCS9） 11ac HT80：-82dBm（MCS0）, -57dBm（MCS9） |
11b：-96dBm（1Mbps），-93dBm（5Mbps），-89dBm（11Mbps）
11g：-91dBm（6Mbps），-85dBm（24Mbps），-80dBm（36Mbps），-74dBm（54Mbps） 11n：-90dBm（MCS0），-70dBm（MCS7），-89dBm（MCS8），-68dBm（MCS15 |
|||
| Spatial Streams | 2×2 | 2×2 | 2×2 | 2×2 | |
| Maximum Transmit Power | 100mW | ||||
| IP Rating | IP41 | ||||
| Ports | 1 10/100/1000BASE-T Ethernet uplink
Port LAN1 supports PoE+ 1 Console Port |
1 10/100/1000BASE-T Ethernet uplink
Port LAN1 supports PoE 1 Console Port |
1 10/100BASE-T Ethernet uplink
Port LAN1 supports PoE |
||
| Power | Power Supply
(DC Power adapters should be purchased from third-party vendors separately if needed.) |
local power supply (DC 48V/0.6A)
PoE (802.3at） |
local power supply (DC 5V/3A)
PoE (802.3af） |
local power supply (DC 12V/1A)
PoE (802.3af） |
|
| Power Consumption | <25.5W | <12.95W | <7.5W | ||
| WLAN | Maximum clients per AP | 768 | 256 | 128 | |
| BSSID capacity | 48 | 32 | 16 | ||
| Remote Intelligent Perception Technology (RIPT) | Support | ||||
| Intelligent load balancing based on the number of users or traffic | Support | ||||
| STA control | Support | ||||
| Bandwidth control | Support | ||||
| Preference for 5GHz (band select) | Support | ||||
| Band Steering (5G Priority) | Support | N/A | |||
| Security | PSK, Web, 802.1x authentication | Support | |||
| PPSK authentication | Support | N/A | |||
| Data encryption | WPA (TKIP), WPA2 (AES), WPA-PSK, and WEP (64 or 128 bits) | ||||
| PEAP authentication | Support | ||||
| User isolation | Support | ||||
| Rogue AP detection and countermeasure | Support | ||||
| RADIUS | Support | ||||
| Wireless Intrusion Detection System(WIDS) | Support | ||||
| Wireless Intrusion Prevention System (WIPS) | Support | ||||
| Routing | IPv4 address | Static IP address or DHCP reservation | |||
| IPv6 address | Manual or automatic configuration | ||||
| Multicast | Multicast to unicast conversion | ||||
| Management and Maintenance | Network management | SNMP v1/v2C/v3, Telnet, TFTP, Web management | |||
| Cloud AC management | Support | ||||
| FAT/FIT switching | Support | ||||
| External Characteristics | Lock | Support | |||
| LED Indicators | 1 LED indicator (red, green, blue, orange, and flashing modes, breathing flashing mode for smart device access, and the indicator can be switched off to enable silence mode) | ||||
| Relevant Standard | Wi-Fi Alliance Certification | Support | |||
| Radio Standard | EN300 328
EN301 893 |
||||
| EMC Standard | GB9254
EN301 489-1 EN301 489-17 EN 55032 EN 61000 EN 55035 |
||||
| Safety Standard | GB4943
EN/IEC 60950-1 |
||||
| Specifications | Dimensions (W x D x H) (mm) | 230x230x42 | 194 × 194 × 37 | 175*175*25.8 | |
| Weight | 1.3kg | 0.42kg | 0.35kg | ||
| Work Environment | Temperature | Operating Temperature:
-10°C to 50°C Storage Temperature: -40°C to 70°C |
Operating Temperature: -10°C to 45°CStorage Temperature: -40°C to 70°C |
||
| Humidity | Operating Humidity:
5% to 95% (non-condensing) Storage Temperature: 5% to 95% (non-condensing) |
||||
