Ruijie RG-AP180 Wall Access Point
Rp4.523.250
- Ruijie RG-AP180 Wall AP Series is a next-generation Wi-Fi 6 (802.11ax) with built-in IoT module wall plate wireless access point designed for hotels, offices and dormitories with Smart IoT integration demands.
| Model | RG-AP180 | ||
| Hardware specifications | |||
| Radio | Dual-radio dual-band：
Radio 1: 2.4G 11ax: 2×2 MIMO Radio 2: 5G 11ax: 2×2 MIMO |
||
| Protocol | Support concurrent 802.11a/n/ac/ax and 802.11b/g/n/ax | ||
| Operating Bands | 802.11b/g/n/ax ：2.4G ~ 2.483GHz
802.11a/n/ac/ax ： 5.150～5.350GHz，5.47～5.725GHz，5.725～5.850GHz (vary depending on different countries) |
||
| Spatial Streams | 4 spatial streams, 2×2 MIMO | ||
| Max Throughput | Maximum throughput of 2.4G: 574Mbps
Maximum throughput of 5G: 1.2Gbps Maximum throughput per AP: 1.775Gbps |
||
| Modulation | 11b：DSS:[email protected]/11Mbps,DQPSK@2Mbps,DBPSK@1Mbps
11a/g：OFDM:64QAM@48/54Mbps,16QAM@24Mbps,QPSK@12/18Mbps,BPSK@6/9Mbps 11n：MIMO-OFDM:BPSK,QPSK,16QAM,64QAM 11ac：MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM 11ax: MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM,1024QAM |
||
| Transmit Power | ≤100mw（20dBm, radio transmit power only） | ||
| Dimensions | 116mm * 86mm *40mm | ||
|
Weight |
0.37kg | ||
|
Service Ports |
Front： 4 10/100/1000Mbps Ethernet ports Rear： 1 10/100/1000Mbps uplink port |
||
|
Power Supply |
Support PoE
Support local power supply (DC Power adapters should be purchased from third-party vendors separately if needed) |
||
| 11ax Feature | Support 802.11ax
Support MU-MIMO |
||
| Management Port | 1 Micro USB port (hidden) | ||
|
Reset |
Support (hidden) | ||
|
LED indicator |
Support (hidden)
The indicator can be switched off |
||
|
Built-in Antenna |
Built-in low-radiation omnidirectional antenna (antenna gain 3.5dBi) | ||
|
IoT Protocol |
Support Bluetooth5.0（BLE）, Zigbee | ||
| Power Consumption | ＜10W | ||
| IP Rating | IP41 | ||
| Anti-theft | Standard: ordinary screws | ||
|
Color of AP Enclosure |
White | ||
|
Wi-Fi Alliance |
· Wi-Fi CERTIFIED™ a, b, g, n, ac
· Wi-Fi CERTIFIED 6™ · WPA3™-Enterprise, Personal · Wi-Fi Enhanced Open™ · Wi-Fi Agile Multiband™ · WMM® |
||
|
Relevant Standard |
Safety Standard | EN/IEC 62368-1 | |
| EMC Standard | EN301 489, EN55032, EN55035 | ||
| Health Standard | EN 62311 | ||
| Radio Standard | EN300 328, EN301 893 | ||
| Environment | Operating temperature：0°C～45°C | ||
| Storage temperature：-40°C～70°C | |||
| Operating humidity：5％～95％（non-condensing） | |||
| Storage humidity：5％～95％（non-condensing） | |||
| MTBF | 250,000 hours | ||
| Installation Mode | Compatible with UK/US/EU
Junction box *Universal Mount Kit need to purchase separately for US/EU junction box |
||
| Software Specifications | |||
| WLAN | Maximum clients per AP | 1024 | |
| BSSID capacity | 8（recommended to configure a maximum of 5 BSSIDs per radio in actual application） | ||
|
SSID hiding |
Support |
||
|
Configuring the authentication mode, encryption mechanism and VLAN attributes for each SSID |
Support |
||
|
Remote Intelligent Perception Technology (RIPT) |
Support |
||
| Intelligent load balancing based on the number of users or traffic | Support | ||
| STA control | SSID/radio-based | ||
| Bandwidth control | STA/SSID/AP-based speed control | ||
| Security | PSK, Web, and 802.1x authentication | Support | |
| Data encryption | WPA (TKIP), WPA2 (AES), WPA-PSK, and WEP (64 or 128 bits) | ||
| QR code authentication | Support (integration with RG-WS series wireless controller) | ||
| SMS authentication | Support (integration with RG-WS series wireless controller) | ||
| PEAP authentication | Support (integration with RG-WS series wireless controller) | ||
| Data frame filtering | Whitelist, static/dynamic blacklist | ||
| User isolation | Support | ||
| Rogue AP detection and countermeasure | Support | ||
| Dynamic ACL assignment | Support | ||
| RADIUS | Support | ||
| CPU Protection Policy (CPP) | Support | ||
| Network Foundation Protection Policy (NFPP) | Support | ||
| Wireless Intrusion Detection System (WIDS) | Support | ||
| Routing | IPv4 address | Static IP address or DHCP | |
| IPv6 | Support | ||
| Multicast – IGMP Snooping | Support | ||
| Management and Maintenance |
Supported wireless LAN controllers |
Ruijie WS Series Wireless Controller
Ruijie MACC-Base Software Controller Ruijie Cloud (Public Cloud) |
|
| Management protocol | Telnet, SSH, TFTP, Web | ||
| Wireless Intelligent AI Optimization Service (WIS) | Support | ||
| SNMP | SNMPV1,V2c,V3 | ||
| Syslog / Debug | Support | ||
| FAT/FIT/MACC mode switching | Factory default firmware supports FAT (standalone) or FIT mode (WS controller) or MACC mode (Ruijie MACC-Base or Ruijie Cloud) management | ||
