Deskripsi
| Management I/O |
(1) RJ-45 console port (1) USB port (1) Micro USB console port |
| Storage Capacity |
| 240GB SSD |
| Power Supply (Average Power Consumption) |
| PA-850: Two 500W AC power supplies. One power supply is redundant. (75W) PA-820: 200W power supply. (45W) |
| Max BTU/hr |
| 256 |
| Input Voltage (Input frequency) |
| 100-240VAC (50-60Hz) |
| Max Current Consumption |
| 2.0A @ 100VAC,1.0A @ 240VAC (PA-850) 1.0A @ 100VAC,0.5A @ 240VAC (PA-820) |
| Max Inrush Current |
| 1.0A @ 230VAC,1.84A @ 120VAC (PA-850) 0.4A @ 230VAC,0.96A @ 120VAC (PA-820) |
| Rack Mountable (Dimensions) |
| PA-850 – 1U, 19” standard rack (1.75”H x 14.5”D x 17.125”W) PA-820 – 1U, 19” standard rack (1.75”H x 14”D x 17.125”W) |
| Weight (Stand-Alone Device/As Shipped) |
| PA-850 13.5lbs/21.5 lbs PA-820 11lbs/18 lbs |
| Safety |
| cCSAus, CB |
| EMI |
| FCC Class A, CE Class A, VCCI Class A |
| Certifications |
| See: https://www.paloaltonetworks.com/company/certifications.html |
| Environment |
| Operating temperature: 32° to 104° F, 0° to 40° C Non-operating temperature: -4° to 158° F, -20° to 70° C |
| Airflow |
| Front to back |
