Outlet Data Schneider AvatarOn, USB charger, type A + C, 2.1…3 A, White
Rp955.999
Deskripsi
Specification
| Product or component type | USB charger |
|---|---|
| Device application | Charger |
| Integrated connection type | USB type A 5 V, maximum load current: 2.1 A USB type C 5 V, maximum load current: 2.1 A |
| device mounting | Flush |
|---|---|
| Device presentation | Complete product |
| Colour tint | White (RAL 9003) |
| Surface finish | Glossy |
| Surface treatment | Polished |
| Ambient air temperature for storage | -5…60 °C |
| Relative humidity | 0…95 % |
| [Ue] rated operational voltage | 100/240 V 50/60 Hz |
| Power consumption in W | 21 W |
| maximum load current with 2 outputs used simultaneously | 3 A |
| Material | PC (polycarbonate) |
| Connections – terminals | Screw terminals |
| Clamping connection capacity | 2.5 mm² for stranded cable(s) 2.5 mm² for solid cable(s) 1.5 mm² for stranded cable(s) 1.5 mm² for solid cable(s) |
| Wire stripping length | 8 mm |
| Product compatibility | HTC XiaoMi Apple Samsung HW Major smart phone and tablet |
| Height | 86 mm |
| Width | 86 mm |
| Depth | 40.1 mm |
| Embedding depth | 30.4 mm |
| Product weight | 0.1292 kg |
| standards | MS IEC 60950-1 IEC 60950-1 IEC 62368-1 IEC 61558-2-16 |
|---|---|
| Product certifications | IEC |
| Electrical insulation class | Class II |
| IP degree of protection | IP20 |
| Environmental characteristic | Liquid soap Alcohol Petrol |
