Huawei Industrial Router AR509G-L-D-H
- HARGA HUBUNGI KAMI
|
Item |
Specification |
|---|---|
|
System parameters |
|
|
Processor |
Dual-core, 1 GHz |
|
Memory |
512 MB |
|
Flash |
512 MB |
|
Micro SD card (default: sd1) |
None |
|
Hard disk |
Not supported |
|
Dimensions and weight |
|
|
Dimensions (H x W x D) |
190 mm x 220 mm x 44 mm (7.5 in. x 8.7 in. x 1.73 in.) |
|
Weight |
1.52 kg (3.35 lb) |
|
Power specifications |
|
|
Rated input voltage (DC) |
12 V |
|
Maximum input voltage (DC) |
10.8 V to 13.2 V |
|
Maximum output current |
1 A |
|
RPS power supply |
Not supported |
|
PoE power supply |
Supported |
|
Power consumption |
|
|
Maximum power consumption |
12 W |
|
Heat dissipation |
|
|
Fans |
None |
|
Airflow (facing the front panel) |
None |
|
Interface density |
|
|
Management interfaces |
1 (RJ45) |
|
CON/RS232 Interface |
1 (RJ45) |
|
USB 2.0 interfaces |
1 |
|
Service interfaces (standard configuration) |
WAN interfaces: one GE electrical interface, one VDSL interface and two LTE antenna interfaces LAN interfaces: four GE electrical interfaces |
|
Extended slots |
Not supported |
|
Environment parameters |
|
|
Operating temperature |
NOTE:
When the altitude is between 1800 m and 5000 m, the highest operating temperature reduces by 1°C every time the altitude increases by 220 m. |
|
Storage temperature |
-40°C to +85°C (-40°F to +185°F) |
|
Operating relative humidity |
5% to 95%, noncondensing |
|
Operating altitude |
< 5000 m (16404.2 ft.) |
|
Part number |
50010221 |
AR509G-L-D-H datasheet.pdf
