Huawei Enterprise Router AR2220E-S
Rp28.038.600
|
Item |
Specification |
|---|---|
|
System parameters |
|
|
Processor |
Quad-core, 1 GHz |
|
Memory |
1 GB |
|
Flash |
512 MB |
|
Micro SD card (default sd1) |
2 GB |
|
Hard disk |
Not supported |
|
Dimensions and weight |
|
|
Dimensions (H x W x D) |
|
|
Weight |
6 kg (13.22 lb) |
|
Power specifications |
|
|
Rated input voltage range (AC) |
100 V to 240 V, 50 Hz/60 Hz |
|
Maximum input voltage range (AC) |
90 V to 264 V, 47 Hz to 63 Hz |
|
Maximum input current |
3 A |
|
Maximum output power |
150 W |
|
RPS power supply |
Supported |
|
PoE power supply |
Not supported |
|
Power consumption (empty chassis) |
|
|
Typical power consumption |
27 W |
|
Maximum power consumption |
29 W |
|
Heat dissipation |
|
|
Fans |
Built-in, unpluggable fans |
|
Airflow (facing the front panel) |
Left to right |
|
Interface density |
|
|
Management interfaces |
1 (RJ45) |
|
CON/AUX interface |
1 (RJ45) |
|
USB 2.0 interfaces |
2 |
|
Service interfaces |
WAN interfaces: one GE combo interface and two GE electrical interfaces |
|
Extended slots |
|
|
DSP DIMM slot |
Supported |
|
Environment parameters |
|
|
Operating temperature |
0°C to 45°C (32°F to 113°F) NOTE:
When the altitude is 1800 m-5000 m (5906ft.-16404.2 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). |
|
Storage temperature |
-40°C to +70°C (-40°F to +158°F) |
|
Operating relative humidity |
5% to 95%, noncondensing |
|
Operating altitude |
< 5000 m (16404.2 ft.) |
|
Part number |
02351ATY |
