Cisco Nexus 9300 with 32p 40G QSFP (N9K-C9332PQ)
Rp512.653.500
Deskripsi
N9K-C9332PQ Specification |
|
| Ports | 32 QSFP+ ports |
| Supported speeds | 40 Gigabit Ethernet speeds |
| Power supplies (up to 2) | 650-watt (W) AC, 930W DC, or 1200W HVAC/HVDC |
| Typical power (AC) | 228W |
| Maximum power (AC) | 508W |
| Input voltage (AC) | 100 to 240V |
| Input voltage (HVAC) | 200 to 277V |
| Input voltage (DC) | -40V to -72V DC (min-max)
-48V to -60V DC (nominal) |
| Input voltage (HVDC) | –240 to –380V |
| Frequency (AC) | 50 to 60 Hz |
| Fans | 4 |
| Physical (H x W x D) | 1.72 x 17.3 x 22.5 in. (4.4 x 43.9 x 57.1 cm) |
| Acoustics | 49.1 dBA at 40% fan speed, 65.6 dBA at 70% fan speed, and 78.5 dB at 100% fan speed |
| RoHS compliance | Yes |
| Weight | 22 lb (10.0 kg) (without power supplies or fans) |
