Cisco Integrated Service Router C2811-SHDSL-V3/K9
Rp46.886.400
- 2811 DSL bundle
- WIC-1SHDSL-V3 (4-wire)
- SP Svcs
- 128F/512D
Deskripsi
| Communications | |
|---|---|
| Digital Signaling Protocol: | SHDSL |
| Max Transfer Rate: | 4.6 Mbps |
| Protocols & Specifications: | ITU G.991.2 (G.shdsl) |
| Type: | DSL modem |
| Dimensions & Weight | |
|---|---|
| Depth: | 41.7 cm |
| Height: | 4.5 cm |
| Weight: | 6.4 kg |
| Width: | 43.8 cm |
| Environmental Parameters | |
|---|---|
| Humidity Range Operating: | 5 – 95% |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Expansion / Connectivity | |
|---|---|
| Expansion Slots: | 2 (total) / 2 (free) x AIM ¦ 4 (total) / 3 (free) x HWIC ¦ 2 (total) / 1 (free) x PVDM ¦ 1 (total) / 0 (free) x CompactFlash ¦ Memory ¦ 1 (total) / 1 (free) x NME |
| Interfaces: | USB: 2 x ¦ Serial: 1 x auxiliary – RJ-45 ¦ Management: 1 x console – RJ-45 ¦ 2 x 10Base-T/100Base-TX – RJ-45 ¦ WAN: 1 x SHDSL – RJ-11 |
| General | |
|---|---|
| Compliant Standards: | NEBS level 3, CISPR 22 Class A, CISPR 24, EN 61000-3-2, VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55024, EN55022 Class A, UL 60950, EN50082-1, CSA 22.2 No. 60950, AS/NZ 3548 Class A, JATE, FCC Part 15, ICES-003 Class A, CS-03, EN 61000-6-2 |
| Connectivity Technology: | Wired |
| Data Link Protocol: | Ethernet, Fast Ethernet |
| Device Type: | Router |
| Enclosure Type: | Desktop – modular – 1U |
| Encryption Algorithm: | DES, Triple DES, AES |
| Features: | Firewall protection, 128-bit encryption, hardware encryption, MPLS support, VLAN support, URL filtering, 256-bit encryption |
| Flash Memory: | 64 MB (installed) / 256 MB (max) |
| Network / Transport Protocol: | IPSec |
| RAM: | 256 MB (installed) / 760 MB (max) |
| Remote Management Protocol: | SNMP 3 |
| IP Telephony | |
|---|---|
| VoIP Protocols: | H.323 |
| Voice Codecs: | G.711, G.723.1, G.729a, G.726 |
| Power | |
|---|---|
| Power Device: | Internal power supply |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Software / System Requirements | |
|---|---|
| OS Provided: | Cisco IOS |
| Software Included: | Cisco IOS SP Services |
