Cisco Aggregation Series Router ASR1002-10G-FPI/K9 - Gambar 1
Click to enlarge
Cisco Aggregation Series Router ASR1004-10G-FPI/K9
Cisco Aggregation Series Router ASR1004-10G-FPI/K9 Rp1.227.105.000
Back to products
Cisco Aggregation Series Router ASR1K6R2-20G-VPNK9
Cisco Aggregation Series Router ASR1K6R2-20G-VPNK9 Rp1.886.445.000

Cisco Aggregation Series Router ASR1002-10G-FPI/K9

Rp1.098.900.000

Compare
Add to wishlist
SKU: ASR1002-10G-FPI/K9 Kategori: , , Tag: ,
Deskripsi
SPESIFICATION

Device Type Modular expansion base – with Cisco ASR 1000 Series Embedded Services Processor, 10Gbps
Enclosure Type Desktop – modular – 2U
Connectivity Technology Wired
Compliant Standards CISPR 24, EN55022, VCCI Class A ITE, EN55024, CISPR 22, EN50082-1, CSA 22.2 No. 60950, EN 61000-6-1, AS/NZS 60950-1, AS/NZ 3548 Class A, ICES-003 Class A, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1
RAM 4 GB
Expansion / Connectivity
Interfaces 4 x SFP (mini-GBIC)
Expansion Slots 3 expansion slot ¦ 1 expansion slot
Installed Modules Qty (Max) 4 (max)
Power
Power Device Internal power supply
Power Redundancy Yes
Installed Qty 2 (installed) / 2 (max)
Voltage Required AC 120/230 V (50/60 Hz)
Miscellaneous
Rack Mounting Kit Included
Software / System Requirements
Software Included Cisco IOS Advanced Enterprise Services
Dimensions & Weight
Width 17.2 in
Depth 21.9 in
Height 3.5 in
Environmental Parameters
Min Operating Temperature 41 °F
Max Operating Temperature 104 °F
Humidity Range Operating 5 – 90%

cisco-asr1000-aggregation-routers-2.pdf
