APC Smart UPS SRT Lead-acid 1500VA RM 230V (SRTL1500RMXLI)
Output
|
| Max Configurable Power (Watts) |
1.35kWatts / 1.5kVA |
| Output Voltage Distortion |
Less than 2 % |
| Output Frequency (sync to mains) |
50/60 Hz +/- 3 Hz Sync to mains |
| Other Output Voltages |
220, 240 |
| Load Crest Factor |
3 : 1 |
| Topology |
Double conversion online |
| Waveform type |
Sine wave |
| Bypass |
Built-in bypass |
Input
|
| Input frequency |
40 – 70 Hz Auto-sensing |
| Input voltage range for main operations |
50 – 150 40% load, 80 – 150V |
| Other Input Voltages |
220, 240 |
Batteries & Runtime
|
| Battery type |
Lead-acid |
| Typical recharge time |
6hour(s) |
| Nominal Battery Voltage |
48 V |
| Expected Battery Life (years) |
5 – 10 |
| Battery Charge Power (Watts) |
103 Watts |
| Battery Volt-Amp-Hour Capacity |
585 |
Communications & Management
|
| Interface Port(s) |
RJ-45 Serial, Smart-Slot, USB |
| Control panel |
Multifunction LCD status and control console |
| Audible Alarm |
Audible and visible alarms prioritized by severity |
| Emergency Power Off (EPO) |
Yes |
| Available SmartSlot™ Interface Quantity |
1 |
Surge Protection and Filtering
|
| Surge energy rating |
340Joules |
| Physical |
| Maximum Height |
128MM, 12.8CM |
| Maximum Width |
432MM, 43.2CM |
| Maximum Depth |
590MM, 59.0CM |
| Net Weight |
30.53KG |
Conformance
|
| Approvals |
CE, CE Mark, EAC, RCM, VDE |
| Standard warranty |
5 year repair or replace |
APC_Smart-UPS On-Line_SRT1500RMXLI-Datasheet.pdf
