Advantech EPD-053 Solution for 20 pcs (EPD-053R2AG-NTC12)
- ARM Cortex-M3 Core Processor
- Supported IEEE 802.15.4 / 2.4 G networks
- 5.65″ ePaper panel display
- Great for Low Consumption, up to 3 years life time
- Rich I/O control with 1 button & 2 color of 1 LED
- Supported temperature 0 ~ 40 °C
Deskripsi
| Category | Attribute | Value |
| Display | Resolution | 600×448 pixels |
| Size | 5.6″ (125.4×99.5mm) | |
| I/O | Button | 1 |
| Processor | Flash | 512 KB |
| MCU | TI 32-bit ARM Cortexx-M3 Processor | |
| RAM | 28 KB | |
| Environment | Operating Humidity | 5~80% Relative humidity, non-condensing |
| Operating Temperature | 0 ~ 40° C (32 ~ 104° F) | |
| Power | Battery | CR2450 x4 |
| Certification | RF | CE/FCC/NCC |
| Mechanical | Dimensions | 36.7×85.6 mm |
| Indicator | LED | 1 |
| Wireless | Channels | 16 |
| Frequency | 2.4 GHz | |
| Function | End node | |
| Receiver Sensitivity | -100 dBm | |
| RF Data Rate | Up to 250 Kbps | |
| Standard | IEEE 802.15.4 | |
| Transmit Power | -21 dBm~+5dBm |
Informasi Tambahan
| Brand | Advantech |
|---|
