Advantech EKI-1221R-CE 1-port Modbus Gateway/Router

Deskripsi

Category	Attribute	Value
Power	Power Consumption	3.2W
Power	Power Operating Current	0.7A @ 24 V
Software	Configuration	Windows utility, Web Browser
Software	Driver	Windows XP/7/8.1/10, Windows Server 2003/2008/2012/2016/2019, and Linux
Software	Operation Mode	Modbus RTU Master/Slave mode;Modbus ASCII Master/Slave mode
Software	Protocols	Modbus RTU, Modbus TCP, Modbus ASCII
Environment	Humidity (Operating Range)	5~95% RH
Environment	Temperature (Operating Range)	-10 ~ 60°C (14 ~ 140°F)
Environment	Temperature (Storage Range)	-20 ~ 80°C (-4 ~ 176°F)
Mechanism	Dimensions (W x H x D)	30 x 140 x 95 mm (1.18′ x 5.51′ x 3.74 in.)
Mechanism	Enclosure (Metal)	Metal with solid mounting hardware
Mechanism	Mounting	DIN-rail, Wall mount
Mechanism	Weight	0.472 kg
Ethernet Communication	Ethernet Standard	IEEE 802.3 , 802.3ab , 802.3u
Ethernet Communication	RJ-45 Port Connector Type	RJ-45
Ethernet Communication	RJ-45 Port Number	2
Ethernet Communication	RJ-45 Transmission Speed	10/100 Mbps
Certification	EMC	CE, FCC
Certification	EMI	EN 55011/ EN 55032 Class A, EN 61000-6-4, FCC Part 15 Subpart B Class A
Certification	EMS	EN 61000-4-2 (Level 4), EN 61000-4-3 (Level 3), EN 61000-4-4 (Level 4), EN 61000-4-5 (Level 4), EN 61000-4-6 (Level 3), EN 61000-4-8 (Level 4), EN55024
Certification	Freefall	IEC 60068-2-32
Certification	Safety	UL 60950-1
Certification	Shock	IEC 60068-2-27
Certification	Vibration	IEC 60068-2-6
MTBF	Method	–
MTBF	Time	–
Warranty	Warranty Period	5 years
