Advantech COMPUTER SYSTEM, WISE-3610 Private LoRa Network IoT Gateway NA915 (WISE-3610ILS-51A1N)
- Qualcomm Atheros Quard-Core ARM Cortex-A7 SoC
- Built-in Dual Band Concurrent Wi-Fi MU-MIMO (2×2)
- LPWAN LoRa Private (WISE-Link) Connectivity
- WAN x1 / LAN x1 Gigabit Ethernet
- IPSec / L2TP VPN Traffic Encryption
- Rich Network Scanrio by S/W Configuration
Deskripsi
| Category | Attribute | Value |
| Memory | Capacity | On-board DDR3L 256MB |
| Memory | Flash | 128 NAND Flash |
| Memory | Technology | DDR3L 1600 MHz |
| Processor | CPU | QCA Quad-core ARM Cortex A7 CPU 716 MHz |
| Operating System | Linux | OpenWRT Barrier Breaker (Linux 3.14) |
| Environment | Operating Humidity | 10% ~ 95% @ 40°C relative humidity, non-condensing |
| Environment | Operational Temperature | -20 ~ 70° C |
| Power | DC-input | DC 9~24V |
| Power | Power Consumption (Max) | 18W |
| Power | Power Type | DC-in |
| Ethernet | Chipset | QCA8075 PSGMII |
| Ethernet | PoE | N/A |
| Ethernet | Speed | 2 x 10/100/1000Mbps |
| Graphics | HDMI | N/A |
| Graphics | VGA | N/A |
| Watchdog Timer | WatchDog Timer | Yes |
| Certification | EMC | SRRC/NCC/TELEC/CE/FCC/IC Class B |
| Expansion | Antenna Hole | 6 x SMA |
| Expansion | SIM Socket | 2 x Micro SIM slot |
| Mechanical | Dimensions (with a metal plate) | 213.5 x 150 x 44 mm |
| Mechanical | Dimensions (without a metal plate) | 188 x 150 x 39 mm |
| Mechanical | Mounting | Metal bracket wall mount |
| Mechanical | Weight | 0.9kg |
| RTC | RTC | Yes |
| WSN | Channel Separation | 200 KHz / 600 KHz |
| WSN | Frequency Band | 902-928MHz |
| WSN | Network Topology | Star |
| WSN | Number of Channel | 64 / 8 |
| WSN | Output Power | 20 dBm |
| WSN | Raw Data Rate | 5470 bps / 21900 bps |
| WSN | Standard | LoRa Private Network – WISE-Link |
| WSN | WSN Network size | 500 nodes |
| Wireless | Cellular | Option for 3G/LTE card |
| Wireless | WiFi | 2×2 IEEE802.11a/b/g/n/ac MU-MIMO 2.4GHz / 5GHz |
| Indicator and Button | Audio | N/A |
| Indicator and Button | Button | 1 reset button for system reboot |
| Indicator and Button | CANBus | N/A |
| Indicator and Button | GPIO | N/A |
| Indicator and Button | I2C | N/A |
| Indicator and Button | LED | 6, PWR/LoRa/Wi-Fi 2G/Wi-Fi 5G/USB/WWAN |
| Indicator and Button | Mini PCIe Socket | 1 Full size mini PCIe slot |
| Indicator and Button | SD Socket | 1 x microSD socket |
| Indicator and Button | Serial Port | 1 x RS-232/422/485 (DB9 Male) |
| Indicator and Button | Switch | N/A |
| Indicator and Button | USB | 1 x USB 3.0 |
