Advantech CIRCUIT BOARD, Board for RISC SMARC v1.0 & v1.1 Modules (ROM-DB5900-SWA2E)
Deskripsi
| Category | Attribute | Value |
| Display | HDMI | 1 HDMI TypeA |
| Display | LVDS | 2 Single channel 24-bit LVDS |
| Form Factor | Form Factor | Advantech SMARC CPU Module Series |
| I/O | Audio | 1 1/8 Audio Jack (I2S HD Audio) |
| I/O | Button | 5 |
| I/O | Camera Input | 2 MIPI connectors |
| I/O | CAN | 2 CAN 2.0B ports, Differential mode +5V |
| I/O | GPIO | 12 GPIO Ports |
| I/O | I2C Bus | 1 I2C pin header |
| I/O | SATA | 1 SATAII Connector (with SATA-DOM support) |
| I/O | SATA Power | 1 |
| I/O | SDIO | 1 SD card slot |
| I/O | Serial port | 4 UART Ports |
| I/O | SPI Bus | 2 SPI pin header |
| I/O | USB | 2 USB 2.0 Type A (Host), 1 min USB Type AB (OTG) |
| Environment | Humidity | 0% ~ 90% relative humidity, non-condensing |
| Environment | Operational Temperature | -40° C ~ 85° C |
| Power | Power Supply Voltage | +12V |
| Power | Power Type | 4 Power Inputs (+12V DC-Jack, +12V 4pin, ATX power, +12V battery) |
| Ethernet | Speed | 2 x 10/100/1000Mbps |
| Certification | EMC | CE/FCC |
| Expansion | SD Socket | 1 SD card slot |
| Physical | Dimension (mm) | 305 x 244 mm (12″ x 9.6″) |
| Expansion Interface | PCIe | 1 PCIe x1 |
Informasi Tambahan
| Brand | Advantech |
|---|
